Odontogenic myxoma in the mandible

Myxomas can be found in various sites in the body including the skin and subcutaneous tissue, heart (mainly in the left atrium), and also in various sites of the head and neck.¹ Odontogenic  myxoma (OM) is the second most common odontogenic  lesion with an incidence of approximately 0.07 new cases/million /year.² World Health Organization has classified OM as a benign tumor of ectomesenchymal origin with or without odontogenic epithelium. It appears to originate from the dental papilla, follicle or periodontal ligament. Myxomas are non-encapsulated benign locally aggressive tumors which may occur in both the soft tissues and bone. In 1863 Virchow was the first man to describe about myxomas.³

CASE REPORT

A nineteen-year-old female patient had visited our department with the chief complaint of swelling on the left side of the mandible since two months with occasional dull aching pain. History revealed that the swelling was small and gradually increased in size. Patient also gave a history of extraction in the same region one year back. Medical history was non-contributory. On Extraoral examination, no gross facial asymmetry was noted.  On intraoral examination there was mild expansion of the buccal cortical plates in the left mandibular premolar region (Fig 1) with no vestibular obliteration. 35 was missing. Restorations were present in 33, 34 and 36. No tenderness and parasthesia were present. No lymph node enlargement was present.  Based on the history and clinical examination, Provisional diagnosis of Residual cyst was given.  To confirm the diagnosis, certain radiographs were advised. Mandibular occlusal radiograph revealed multilocular radiolucency extending from 32 to 36 region with expansion of the buccal cortical plates (Fig 2). Panoramic radiograph revealed multilocular radiolucency with angular septations extending from 36 to 42. Obturating material present in 33 is extending into the radiolucency. Root resorption in seen with respect to 34,36 (Fig 3).  Cone beam computerized tomography revealed irregular multilocular bone destruction with angular septations. (Fig 4)

Figure 1

Mild expansion of the buccal cortical plate irt 34,36 region

Figure 2

Mandibular occlusal radiograph revealed multilocular radiolucency extending from 32 to 36 region with  expansion of the buccal cortical plates

Figure 3

Orthopantomograph  reveals  multilocular radiolucency with angular septations  extending  from 42- 36. Obturating material present in 33 is extending into the radiolucency. Root resorption in seen wrt  34,36

Figure 4

Cone beam computerized radiography reveals Cortical expansion, angular septations and obturative material in 33 in axial and sagittal sections respectively

Fine needle aspiration was negative. Differential diagnosis of Odontogenic keratocyst, Central giant cell granuloma and Odontogenic   myxoma were given. For further confirmation incisional biopsy was advised. Gross sections revealed greyish white glistening, gelatinous mass (Fig 5). Heametoxylin and eosin sections showed stellate cells loosely arranged in a fibrillar stroma which confirmed the diagnosis of Odontogenic myxoma (Fig 6). Treatment plan of segmental mandibulectomy followed by reconstruction using free autogenous graft was planned. However, the patient was lost to follow up.

Figure 5

Gross specimen showed Whitish grey glistening gelatinous mass

Figure 6

Haematoxylin and eosin stain showing stellate shaped cells loosely arranged in myxoid stroma

DISCUSSION

Rudolph Virchow was the first to describe the histologic features of myxofibroma in 1863, although the lesions of jaws were not particularly mentioned. He described that these tumors resemble the mucinous substance of the umbilical cord. These tumors are most frequently seen in heart muscle. Myxomas of the mandible and maxilla are very rare. In 1947, Thoma and Goldman first described myxomas of the jaws. Since then odontogenic myxoma has been a subject of continuous scientific debate.⁴

Odontogenic myxomas (OM) are rare tumors derived from embryonic mesenchymal elements of dental anlage.⁵ World Health Organization has classified OM as a benign tumor of ectomesenchymal origin with or without odontogenic epithelium.⁶ It appears to originate from the dental papilla, follicle or periodontal ligament.⁵

In Asia, Europe and America relative frequencies of occurrence of odontogenic myxomas are between 0.5 and 17.7% have been reported.^{7, 8-13}

Odontogenic myxomas are asymptomatic. Pain, paresthesia or asymmetries occur only when they take on larger sizes. Their growth is usually slow; however, they are locally aggressive. They may cause divergence of root, resorption, tooth shifting or movement. When involving maxilla, OM can expand inside the maxillary sinus and are then diagnosed later only after having grown to larger sizes.¹⁴

Radiological appearance of OM is usually a unilocular or multilocular radiolucency having well-defined or diffused margin. The size of the lesion and locularity are interrelated. OM lesions which are larger than 4 cm follow a multiloculated presentation, whereas smaller lesions seem to be unilocular in appearance and the presentation is often defined as soap bubble, honeycomb, ground-glass, or tennis racket pattern.¹⁵ Kaffe et al reported mixed appearance in 12.5% and radiopaque appearance in 7.5% cases.¹⁶

On gross examination, odontogenic myxoma appears as a grayish white, nodular heterogeneous mass of variable consistency,¹ with a glistening gelatinous cut surface,¹⁷ which was obvious in our case.

In a clinicopathological study conducted on 25 cases of odontogenic myxomas by Li et al (2006), it was seen that histologically, all odontogenic myxomas were mainly composed of spindled or stellate-shaped cells in a mucoid-rich intercellular matrix.¹⁸

In a review conducted by Farman et al (1977) on histochemical findings in odontogenic myxoma it was seen that the ground substance of odontogenic myxomas consist of about 80% hyaluronic acid and 20% chondroitin sulfate. Tumor cells showed slight alkaline phosphatase activity. It was also seen that the myxoid intercellular matrix stains positively with alcian blue, but PAS staining may be negative.¹⁹

The current recommended therapy depends on the size of the lesion and on its nature and behaviour and can vary from curettage to radical excision. Due to its locally invasive nature, OM of the jaws tends to be treated by bone resection including peripheral ostectomy and segmental mandibulectomy.^20,21 These techniques remove a circumferential margin of bone around the tumor. The lesion is not encapsulated and its myxomatous tissue infiltrates the surrounding bone tissue, accounting for a high recurrence rate of 25% with conservative treatment.^22-23 Therefore, radical resection including a margin of 15–20 mm of healthy bone seems to be the best option to prevent recurrences, especially in rapidly expanding or locally destructive lesions with cortical bone perforation.¹¹ These characteristics may explain the high rate of recurrence of myxomas which ranges from 10 to 33%.^24-25

CONCLUSION

Odontogenic myxomas are rare tumors with ambiguous behavior. Odontogenic myxoma share common features with many other odontogenic tumours which may lead to a diagnostic dilemma. The use of plain radiography and advanced imaging modalities such as Computed Tomography and Cone Beam Computed Tomography can help in determining the extension of multilocular lesions like odontogenic myxoma and its effect on the surrounding structures. Proper initial clinicoradiological diagnosis followed by histopathological examination helps in arriving at an appropriate diagnosis and helps in formulating a treatment plan with minimal recurrences.

References

1. F. Canalis, G.A. Smith, H.R. Konrad. Myxomas of the head and neck Arch. Otolaryngol.1976;102:300-305.
2. N.M. Simon, M.A.W. Merkx, E. Vuhahula, D. Ngassapa, P.J.W. Stoeling. Odontogenic myxoma: A clinicopathological study of 33 cases. Int. J. Oral Maxillofacial Surg.2004; 33:333-337.
3. Mustafa K, Selçuk Y. Odontogenic myxomas of the maxilla. Clinics and Practice.2011;1:304-305.
4. H. Thoma, H.M. Goldman. Central myxoma of the jaw. Am. J. Orthod Oral Surg. 1947;33(7):532-540.
5. Halfpenny W, Verey A, Bardsley V. Myxoma of the mandibular condyle. A case report and review of the literature.. Oral Surg Oral Med Oral Pathol Oral Radiol Endod. 2000 Sep; 90(3):348-53
6. Pindborg JJ, Kramer IRH: Histological typing of Odontogenic tumors. Jaw cysts and Allied lesions. International Histological classification of tumors, No.5, World Health Organization: Geneva; 1971.
7. Keszler A, Dominguez FV, Giannuzio G. Myxoma in childhood. An analysis of 10 cases. J Oral Maxillofac Surg 1995;53(5):518–21
8. Regezi JA, Kerr DA, Courtney RM. Odontogenic tumors: analysis of 706 cases. J Oral Surg. 1978;36(10):771-778.
9. Wu PC, Chan KW. A survey of tumours of the jawbones in Hong Kong Chinese: 1963-1982. Br J Oral Maxillofac Surg. 1985;23(2):92–102.
10. Gunham O, Erseven G, Ruacan S, Celasun B, Ayidutan Y, Ergun E, et al. Odontogenic tumours a series of 409 cases. Aust Dent J 1990;35:518–22.
11. Daley TD, Wysocki GP, Pringle GA. Relative incidence of odontogenic tumours and oral and jaw cysts in a Canadian population. Oral Surg Oral Med Oral Pathol Oral Radiol Endod.1994;77:276–80.
12. Mosqueda-Taylor A, Ledesma-Montes C, Caballero-Sandoral S, Portilla-Robertson J, Godoy-Rivera L, Menenses-Garcia A. Odontogenic tumours in Mexico: a collaborative retrospective study of 349 cases. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 1997;84:672–5.
13. Lu Y, Xuan M, Takata T, Wang C, He Z, Zou Z, et al. Odontogenic Odontogenic tumours. A demographic study of 759 cases in a Chinese population. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 1998;86:707–14.
14. Carvalho de Melo AU, de Farias Martorelli SB, Cavalcanti PH, Gueiros LA, Martorelli Fde O. Maxillary odontogenic myxoma involving the maxillary sinus: Case report. Braz J Otorhinolaryngol. 2008;74:472-5.
15. Higo M, Kasamatsu A, Ogawara K, Shiiba M, Uzawa K, Tanzawa H. A case of a rapidly expanding odontogenic myxoma of the mandible. Oral Sci Int. 2015;12:22-6.
16. I Kaffe, Η Naor and Α Büchner .Clinical and radiological features of odontogenic myxoma of the jaws.Dentomaxillofacial Radiology .1997;26:299-303.
17. E. Landa, M.H. Hedrick, M.C. Neopomunoceno-Perez, G.C. Sotereanos.Recurrent myxoma of the zygoma: a case report. J. Oral Maxillofacial Surg., 2002;60:704-708
18. Tie-Jun Li, PhD; Li-Sha Sun,; Hai-Yan Luo. Odontogenic Myxoma: A Clinicopathologic Study of 25 Cases. Arch Pathol Lab Med .2006;130:1799–1806
19. Farman AG, Nortje CJ, Grotepass FW, Farman FJ, Van Zyl JA. Myxofibroma of the jaws. Br J Oral Surg. 1977;15:3–18.
20. Hirai, K. Yamamoto, H. Yonemasu, et al. Odontogenic myxoma containing osteocement-like tissue: report of a case with an unusual histopathological feature. J Oral Maxillofac Surg Med Pathol.2014;26:407-41
21. Leiser, I. Abu-El-Naaj, M. Peled. Odontogenic myxoma – a case series and review of the surgical management.J Craniomaxillofac Sur. 2009;37:206-209
22. L. Muzio, P.F. Nocini, G. Favia, et al. Odontogenic myxoma of the jaws. Oral Surg Oral Med Oral Pathol Oral Radiol Endod.1996; 82: 426-433
23. A. Regezi, D.A. Kerr, R.M. Courtney. Odontogenic tumors: analysis of 706 cases. J Oral Maxillofac Surg.1978;36:771-778
24. O. Abiose, H.A. Ajagbe, O. Thomas. Fibromyxomas of the jawbones – a study of ten cases. Br. J. Oral Maxillofacial Surg.1987;25(5):415-421.
25. Lo Muzio, P. Nocini, G. Favia, M. Procaccini, M.D. Mignogna. Odontogenic myxoma of the jaws: a clinical, radiologic, immunohistochemical and ultrastructural study.Oral Surg. Oral Med. Oral Pathol. Oral Radiol. Endod. 1996;82(4):426-433
